Sibom Skid Steer Lateral Fork, durable and high-strength materials, 2645 Ibs lifting capacity, lateral movement

Sibom Skid Steer Lateral Fork, durable and high-strength materials, 2645 Ibs lifting capacity, la...

Contact Us
  • Compatible with major wheel loader & skid steer brands
  • Heavy-duty construction for demanding job sites
  • OEM customization available on request
  • Professional technical support & after-sales service

Product Overview

Hydraulic lateral movement ±10” for precise handling. Fork spacing is adjustable from 2” to 50”, with a max lifting capacity of 2,645 lbs (1.2 tons). Compatible with hydraulic systems requiring 8-10 GPM (30-40 L/min) flow and up to 3050 PSI. Features simple hydraulic control for side-to-side movement and easy maintenance.

Sibom Material Handling are designed for reliable performance in demanding working environments. Manufactured with durable materials and advanced engineering, they provide excellent operational efficiency and long service life across construction, agriculture, landscaping and material handling applications.

  • Hydraulic lateral movement ±10” for precise handling.
  • Fork spacing is adjustable from 2” to 50”, with a max lifting capacity of 2,645 lbs (1.2 tons).
  • Compatible with hydraulic systems requiring 8-10 GPM (30-40 L/min) flow and up to 3050 PSI.
  • Features simple hydraulic control for side-to-side movement and easy maintenance.

Key Features

Heavy-duty steel construction

High wear resistance for extended service life

Optimized design for loading efficiency

Suitable for harsh working conditions

OEM customization available

Quality inspection before dispatch

Technical Specifications

Model spf48a
Overall Length (in) 73
Overall Width (in) 51.7
Overall Height (in) 50.5
Theoretical Weight (lbs) 1000.9
Side Shift Distance (in) 0 - 14.1
Maximum Lifting Capacity (lbs) 2645.5
Fork Spacing (in) 10.1 - 44.9
Working Flow Rate (GPM) 7.9 - 10.6
Allowable Maximum Pressure (psi) 3045.8
